Fold Down Bollards: How do you install them?

Installing a fold-down bollard can be a straightforward process if you follow the correct steps. As long as you take things steadily, you’ll be fine. Just don’t rush it! Here's a basic guide to help you install a fold-down bollard in the UK:

Fold down bollard installation - What materials and tools do you need?

1. Fold-down bollard (ensure it comes with installation instructions)
2. Concrete (pre-mixed or mix your own)
3. Gravel or hardcore (for the base)
4. Post-hole digger or shovel (a bit elbow grease never harmed anyone!)
5. Spirit level
6. Tape measure
7. Protective gear (gloves, safety glasses)
8. Bucket or wheelbarrow (for mixing concrete)
9. Water

OK, you’ve got all your stuff. What do you do next?

1. Select the Location
   • Choose a suitable location for your bollard. Make sure it's away from any underground utilities and provides adequate protection for the area you intend to secure.
2. Mark the Spot
   • Use the bollard base plate to mark the spot on the ground where you will install it. Ensure it aligns correctly with the area you want to protect. You may have to carefully remove some driveway tiles or bricks…
3. Dig the Hole
   • Dig a hole for your fold down bollard. The depth should be about 300-400mm (12-16 inches), and the width should be slightly larger than the bollard base. This will allow for a stable installation with concrete.
4. Prepare the Base
   • Place a layer of gravel or hardcore at the bottom of the hole (about 100mm or 4 inches). This helps with drainage and provides a solid base for the concrete.
5. Position the Bollard
   • Place the bollard in the hole. Use a spirit level to ensure it's standing straight.
6. Mix the Concrete
   • Mix the concrete according to the manufacturer's instructions. A standard mix ratio is 1 part cement to 3 parts sand and 3 parts gravel, with enough water to achieve a workable consistency.
7. Pour the Concrete
   • Carefully pour the concrete into the hole around the bollard. Fill the hole completely, ensuring the bollard remains level and upright. Of course, if you’re replacing driveway tiles around the bollard, you’ll need to leave a certain depth so they can be replaced…
8. Smooth the Surface
   • Use a trowel to smooth the surface of the concrete around the base of the bollard. Make sure the concrete is flush with the ground level.
9. Allow to Set
   • Allow the concrete to set for at least 24 hours. Follow the manufacturer's recommendations for drying time, which may be longer.

• Test the Bollard
  • Once the concrete has fully cured, test the bollard by folding it down and locking it in place to ensure it operates smoothly.

Additional Tips

• Check Local Regulations: Ensure you comply with any local planning permissions or regulations regarding the installation of bollards.
• Weather Conditions: Install the bollard on a dry day to ensure the concrete sets properly.
• Maintenance: Regularly check the bollard for any signs of wear or damage, and ensure the locking mechanism functions correctly.

By following these steps, you should be able to successfully install a fold-down bollard, improving the security of your driveway or protected area. Remember, you don’t need to be an expert to install a fold down bollard, so don’t get stressed about it, and you’ll be fine. Take a look at our range of bollards!
